UNITFiber Tapering Equipment
Polarization Maintaining Coupler Fiber Taper (XQ7130)
XQ7130 is used mainly for making polarization maintaining 12/22/13/33/WDM optical fiber splitter, including flexible adjustment of various splitting ratio and wavelength. XQ7130 adopts special method to align panda eyes of PM fiber to realize the manufacturing of high extinction ratio devices, integrates extinction ratio testing system to improve further the production efficiency. XQ7130 is stable , reliable and easy to use.
Key Features
- PM fiber alignment
- High ER retention
- Automated twisting mechanism
- Real-time monitoring
Applications
- PM Coupler Manufacturing
- Quantum Key Distribution
- Gyroscopes
Technical Specifications
| Extinction Ratio Retention | > 25 dB |
| Coupling Ratio Accuracy | ± 1% |
| Rotational Stage Resolution | 0.01° |
