UNITOptical Light Sources
Special Test Light Source (XQ5150)
XQ5150 is a special test light source which is designed independently by OSCOM Technology. In order to meet the special testing needs of customers, it integrates the technology of automatic temperature control (ATC), automatic power control (APC), RS232C communication control, etc.It can provide 1/2/3/4-channel benchtop light source and its typical application wavelengths are 365nm, 532nm, 635/650nm, 780nm, 1064nm etc.XQ5150 is stable, reliable, easy to use and very suitable for testing of optical devices, development of laser equipment and other applications.
Applications
- Optical fiber communication test
- Optical fiber sensing test
- Optical fiber device production and test
- Bio-medical test
- Industrial laser application test
- Special laser application test
Technical Specifications
| Available Wavelengths | 1064nm, 2000nm, etc. (Configurable) |
| Output Power | Application dependent |
